A10 Thunder Series 6430(S) ADC/CGN
Interface Connections
page 4
CAUTION: Do not attempt to install or operate damaged equipment. As with any
electrical equipment, personal injury or damage to other equipment can
result from commissioning damaged electrical equipment.
Regulations
Follow all applicable regulations for installation of electrical equipment.
Unpacking
Carefully unpack your ACOS device and included items from the box.
Check the Contents
Confirm that the following items are included with the ACOS device:
• Cables: one power cable, two Cat-5E Ethernet cable, one Serial to RJ-45 console cable
• Hardware: ear mounting brackets and sliding-rail kit
Table 2
provides details about these kits, including part numbers.
Rack-mount kit installation instructions are available in “Rack-Mount Kit Installation” on page 9
.
Sliding rail kit installation instructions are available in “Sliding Rail Kit Installation” on page 15
.
Other Requirements
Other equipment needed for installation:
• Notebook or workstation PC (Windows, Linux, Mac) with compatible Ethernet connectivity.
• Supported Web browser
• Terminal Emulation Software (PuTTy, HyperTerminal, or similar)
Interface Connections
The A10 Thunder Series 6430(S) model provides the following interfaces:
• Ethernet data interfaces:
• 16 x 10 Gb Fiber (SFP+) data ports (#1 - #16)
• 4 x 40 Gb Fiber (QSFP+) data ports (#17 - #20)
• Management interfaces:
• 1 serial console interface (Console)
