A10 Thunder Series - Slide the Chassis into the Rack

A10 Thunder Series 6430(S) ADC/CGN
Sliding Rail Kit Installation
page 22
FIGURE 16 Back of rail assembly:
FIGURE 17 Front of rail assembly aligned with rack:
Slide the Chassis Into the Rack
To slide the chassis into the rack:
CAUTION: Lifting the A10 Thunder 6430(S) chassis and placing in the rails is a two-
person job. If needed, use an appropriate lifting device.
