page 21
A10 Thunder Series 6430(S) ADC/CGN
Sliding Rail Kit Installation
3. Extend the outer rail until it reaches the rear of the rack.
4. Insert 2 screws and partially tighten them.
5. Tighten all screws.
FIGURE 15 Front of rail assembly:
