A10 Thunder Series 6430(S) ADC/CGN
Port Splitting Configuration Examples
page 40
Port Splitting Configuration Examples
This section provides examples of port splitting configuration. The CLI commands vary depending on
your ACOS release:
• Configuring Port Splitting in ACOS 2.7.x Releases
• Configuring Port Splitting in ACOS 3.x and 4.x Releases
Configuring Port Splitting in ACOS 2.7.x Releases
To enable splitting of a 40G interface to four 10G interfaces in ACOS 2.7.x and earlier releases:
• Use the 4x10g-mode-enable command to enable port splitting.
• Use the 4x10g-mode-disable command to disable port splitting.
NOTE: You must reboot the computer for either command to take effect.
Enabling Port Splitting
Below is a configuration example:
ACOS(config)# 4x10g-mode-enable
This command will modify your system to enable 4x10g-mode support.
Any configurations on the affected interface(s) and interface references
from VLANs/Trunks/Routing etc. are advised to be removed first,
otherwise the interface configurations may cause errors and/or be lost.
The mode change will take effect starting from the next reboot.
Please confirm to proceed:
Do you want to proceed with the 4x10g-mode command now (N/Y)? : y
4x10g-mode support will be enabled when the system reboots.
Please reboot the system when you are ready...
ACOS(config)# end
ACOS# reboot
System configuration has been modified. Save? [yes/no]:yes
Building configuration...
Write configuration to primary default startup-config
.0 minutes 1 seconds
[OK]
Rebooting System Now !!!
Proceed with reboot? [yes/no]:yes
