A10 Thunder Series User Manual

page 1
Table of Contents
Getting Started ............................................................................................................................. 3
Inspection ...............................................................................................................................3
Interface Connections............................................................................................................4
LED Locations and Status Indicators....................................................................................5
Installation ..............................................................................................................................7
Power-On.................................................................................................................................7
Rack-Mount Kit Installation ..........................................................................................................9
Getting Started .......................................................................................................................9
Rack-Mount Contents ..................................................................................................................................9
Required Tools ........................................................................................................................................... 10
Rack-Mount Installation.......................................................................................................10
Separate the End Brackets from the Inner Rails .................................................................................10
Attach the Inner Rails to the Chassis .................................................................................................... 11
Attach the End Brackets to the Rack ..................................................................................................... 12
Insert the Chassis Into the Rack ............................................................................................................. 13
Sliding Rail Kit Installation ......................................................................................................... 15
Getting Started .....................................................................................................................15
Rail Kit Contents ........................................................................................................................................ 15
Required Tools ........................................................................................................................................... 17
Sliding Rail Kit Installation...................................................................................................18
Attach the Front Brackets to the Chassis ............................................................................................. 18
Attach the Inner Rails to the Chassis .................................................................................................... 19
Attach the Rail Assemblies to the Rack ................................................................................................ 20
Slide the Chassis Into the Rack .............................................................................................................. 22
Fan Hot Swap ............................................................................................................................. 25
Fan Module Location and Fan Numbers.............................................................................25
Removing a Fan Module ......................................................................................................26
Inserting a Fan Module ........................................................................................................26
Power Supply Unit Installation ................................................................................................... 29
Overview................................................................................................................................29
DC Power Supply Installation ..............................................................................................31
Power Supply Hot Swap.......................................................................................................33
Removing a Power Supply ....................................................................................................................... 34
Inserting a Power Supply ......................................................................................................................... 34

A10 Thunder Series Specifications

General

Model	A10 Thunder Series
Category	Network Hardware
Application Delivery	Yes
Advanced Load Balancing	Yes
SSL Insight	Yes
DDoS Protection	Yes
IPv6 Migration	Yes
Hardware Acceleration	Yes
Humidity	5% to 95% non-condensing
Operating Temperature	32°F to 104°F (0°C to 40°C)
Interfaces	10/100/1000/10G/40G/100G Ethernet
Power Supply	Redundant Power Supplies Available
