104
24. External Dimention
GX-203A / GX-303A / GX-403A / GX-603A / GX-1003A / GX-1603A
GF-203A / GF-303A / GF-403A / GF-603A / GF-1003A / GF-1603A
1 Opening width when transparent plate is removed.
2 Inside dimension
3 Weighing pan size
4 Height from the weighing pan to the lid of the breeze break.
5 Opening height when transparent plate is removed.
6 Position under the floor weighing platform.
7 DC jack protruding dimension of AC adapter.
