12.Data Memory
Data memory is a function to store weighing data and calibration data in memory. The data stored in
memory are available for outputting at one time to a printer or personal computer.
The following five types of data can be stored.
Unit mass (Counting mode) Up to 50 sets
Weighing value Up to 200 sets
Calibration report
Internal calibration
External calibration
Calibration test report
Internal test calibration
External test calibration
Last 50 sets
12-1 Data Memory For Weighing Data
Features
□ It is not necessary to connect the printer or personal computer to the balance continually, because
the balance stores the weighing data in memory.
□ The data in memory can be displayed on the balance for confirmation.
□ Data (ID number, data number, time and date) to be added to the output data can be selected in the
function setting.
□ The balance can store 200 sets of weighing data in memory (if time and date are added, the balance
can store 100 sets).
※ For the unit mass storage method, refer to "5-2 Counting Mode".
Storing the weighing data
Note
1. Set the "Data memory (data)" parameter to " data 2". Refer to "10. Function Table".
2. Specify the "Time/Date output (5-td)" parameter whether time and date is to added or not.
3. The storing mode depends on the "Data output mode (prt)" parameter setting.
When set to prt3
(stream mode), data may not be stored correctly.
※
It is also possible to change the time / date setting after storing the weighing value.
Display and symbol
Caution
□ When weighing data is being stored in memory, the data is output simultaneously using RS-232C interface or
USB.
□ "fUl" indicates that memory is full or the memory capacity has been reached. More data cannot be
stored unless the memory data is deleted.
□ Automatic self calibration can not be used while the interval memory mode is active.
□ Statistic calculation function can not be used when the data memory function is active.
Weighing display in
progress
Display of measured weighing
value
Number of stored data
Data number of the
displayed weighing
value
Full memory
When the volume of measured
values stored reaches its
maximum,
fUl dat
blink in turn.
To Next Page
