16 OI/266/PB-EN Rev. E | 2600T Series Pressure transmitters
5 Mounting
142 (5.59)
(*)
179 (7.02)
91 (3.58)
123 (4.86)
113 (4.43)
29 (1.14)
18 (0.71)
18 (0.71)
210 (8.28)
113 (4.45)
11 (0.43)
72 (2.83)
66 (2.60) with plug
78 (3.07) with d/v valve
58 (2.28)
55 (2.17)
Figure 9: Differential Pressure Style transmitter with barrel housing installed on a vertical pipe with optional bracket (B2)
129 (5.06)
197 (7.73)
72 (2.83)
116 (4.57)
136 (5.35)
178 (6.99)
183 (7.19)
29 (1.14)
18 (0.71)
55 (2.17)
113 (4.45)
87 (3.42)
18 (0.71)
Figure 10: Differential Pressure Style transmitter with DIN housing installed on a Vertical pipe with optional bracket (B2) installation for
AIR/GAS measurements
