60 OI/266/PB-EN Rev. E | 2600T Series Pressure transmitters

Appendix A – Device mapping

Idx Parameter Data Type Size Storage Class Range / Selection Note

n+41 DIAGNOSIS_SIMULATION_STATUS RW S U8 1 N

0: Simulation disabled (default)

1: Simulation enabled

n+42 DIAGNOSIS_EXT_SIMULATION RW S O_STR 16 N Error Root cause simulation Simulation of any individual error condition

n+43 DIAGNOSIS_EXT_MASK RW S O_STR 6 N Error Root cause masking Mapped as idx n+14

n+44 ASSEMBLY_DATE R S O_STR 16 Cst Date of when the transmitter has been assembled

n+45 SAVINGS RW S U16 2 N

1 Save actual device conﬁguration as Default

Save the device conﬁguration that can be recovered with

(idx n+19) FACTORY_RESET = 1

32768 Save P-dP Sensor as Factory Calibration

Save the Sensor calibrations as Factory calibration that

can be recovered with (idx n+19) FACTORY_RESET

32769 Save t Static P Sensor as Factory Calibration

32770 Save Sensor Temp as Factory Calibration

32771 Save as User P-dP Sensor Trimming

Save the Sensor calibrations as User calibration that

can be recovered with (idx n+19) FACTORY_RESET

32772 Save as User Static P Sensor Trimming

32773 Save as User Sensor Temp Trimming

n+46 SERVICE RW S U8 1 N

0: Do nothing

Resets all the bits set in (idx n+38)

DIAGNOSIS_EXT_HISTORY

1: Reset Diagnosis History and Details

n+47-81 Reserved by ABB for internal use

VIEWS

n+134 VIEW_1 R 17 D
