sym Error HMI code Description Possible Cause Suggested Actions
Installation/start-up errors
Replace Info
Replace
required – Data
directions valid
M020.042
The Replace operation is required
after the changing of the electronics
or of the sensor
The Electronics or the Sensor have been changed but the
replacement operation has not been executed
The replacement operation must be executed:
- Move the SW 1 of the electronics in position 1 =
Enable replace mode
-Select the SW 2 the element that has been changed
between new Sensor or new electronics
- Power Cycle the device
- Move the SW 1 of the electronics in position 0
Replace
required – FE
to CB not
applicable
The Replace operation is required
after the changing of the electronics
or of the sensor
The Electronics or the Sensor has been changed and a replacement
operation for a new sensor has to be executed.
The replacement operation must be executed:
Only electronics data can be copied into the sensor
- Move the SW 1 to Enable replace mode (1)
- Select with the SW 2 to New Sensor (1)
- Power Cycle the device
- Move the SW 1 to Disable replace mode (0)
Replace
enabled – FE
to CB not
applicable
The Replace operation has been
attempted but with wrong direction
The Electronics or the Sensor have been changed, The replacement
has been enabled but with a wrong direction (SW 2 = 0)
Change the replacement direction (if possible)
- The SW 1 is already set to Enable replace mode (1)
- Select with the SW 2 to New Sensor (1)
- Power Cycle the device
- Move the SW 1 to Disable replace mode (0)
Process errors
Pressure Overrange F104.032 An overpressure has been detected
This effect could be produced by other equipment on the process,
(valves…..). Exceeding the pressure range can cause reduced
accuracy or mechanical damage to the diaphragm material and may
require calibration/replacement.
The compatibility of pressure transmitter model and
process conditions has to be checked. A different
transmitter type could be required
P-dP Out Of Limit F102.004
The measured Process Pressure
value is outside the sensor limits and
no longer representing the true
applied process value.
The measurement range has not been correctly calculated OR an
incorrect transducer model has been selected.
The compatibility of pressure transmitter model and
process conditions has to be checked. Probably a
different transmitter type is required.
Static Pressure Out Of Limit F100.005
The measured Static pressure is
above its operational limit
The static pressure of the process exceeds the limit of the sensor.
Exceeding the Static Pressure can reduce accuracy, mechanically
damage the diaphragm and may require calibration/replacement. An
incorrect transducer model could have been selected.
The compatibility of pressure transmitter model and
process conditions has to be checked. Probably a
different transmitter type is required.
Sensor Temperature Out Of
Limit
S054.006
The measured sensor temperature is
outside of its operational limits
The temperature of the process environment affects the pressure
transmitter; Excess temperature can reduce accuracy, degrade device
components and may require calibration/replacement.
The compatibility of pressure transmitter model and
process conditions has to be checked. A different
installation type could be required e.g. remote seals.
Max. Working Pressure
Exceeded
M052.031
The Static Pressure is higher than the
acceptable mechanical limit for the
process connection elements.
The static pressure of the process exceeds the MWP supported by
the transmitter. Exceeding the MWP can mechanically damage the
process connections (flanges, pipes….) and/or be dangerous
The compatibility of process connections and material
with the process has to be checked. A different
installation type could be required e.g. remote seals.
