Actual signals and parameters 153
0159
PID COMM VALUE 2
Data received from fieldbus for PID control (PID1 and PID2).
0160
DI 1-5 STATUS
Status of digital inputs.
Example: 10000 = DI1 is on, DI2...DI5 are off.
0161
PULSE INPUT FREQ
1 = 1 Hz
Value of frequency input in Hz.
0162
RO STATUS
1 = 1
Status of relay output 1.1 = RO is energized, 0 = RO is de-energized.
0163
TO STATUS
1 = 1
Status of transistor output when transistor output is used as a digital output.
0164
TO FREQUENCY
1 = 1 Hz
Transistor output frequency, when transistor output is used as a frequency output.
0173
RO 2-4 STATUS
Status of the relays in the Relay Output Extension Module MREL-0. See MREL-01
Relay Output Extension Module User’s Manual (3AUA0000035974 [English]).
Example: 100 = RO 2 is on, RO3 and RO 4 are off.
0174
SAVED KWH
0.0 … 999.9 kWh
Energy saved in kWh compared to the energy used when the load is connected
directly to the supply. See the note on page 251.
• The counter value is accumulated till it reaches 999.9 after which the counter rolls
over and starts again from 0.0.
• Can be reset with parameter 4509 ENERGY RESET (resets all energy calculators
at the same time).
• See group Group 45: Energy saving.
0175
SAVED MWH
0 … 65535 MWh
Energy saved in MWh compared to the energy used when the load is connected
directly to the supply. See the note on page 251.
• The counter value is accumulated till it reaches 65535 after which the counter rolls
over and starts again from 0.
• Can be reset with parameter 4509 ENERGY RESET (resets all energy calculators
at the same time).
• See group Group 45: Energy saving.
Group 01: Operating data
Code Description Range Resolution Default S
