Actual signals and parameters 181
1605
USER PAR SET CHG
-5…5 1 0
Defines control for changing the user parameter set.
• See parameter 9902 APPLIC MACRO.
• The drive must be stopped to change User parameter sets.
• During a change, the drive will not start.
Note: Always save the User parameter set after changing any parameter settings, or
performing a motor identification.
• Whenever the power is cycled, or parameter 9902 APPLIC MACRO is changed, the
drive loads the last settings saved. Any unsaved changes to a user parameter set
are lost.
Note: The value of this parameter (1605) is not included in the User parameter sets,
and does not change if User parameter sets change.
Note: You can use a relay output to supervise the selection of User parameter set 2.
• See parameter 1401.
0 = NOT SEL – Defines the control panel (using parameter 9902 APPLIC MACRO) as
the only control for changing User parameter sets.
1 = DI1 – Defines digital input 1 as a control for changing User parameter sets.
• The drive loads User parameter set 1 on the falling edge of the digital input.
• The drive loads User parameter set 2 on the rising edge of the digital input.
• The User parameter set changes only when the drive is stopped.
2…5 = DI2…DI5 – Defines digital input DI2…DI5 as a control for changing User
parameter sets.
• See DI1 above.
-1 = DI1(INV) – Defines an inverted digital input 1 as a control for changing User
parameter sets.
• The drive loads User parameter set 1 on the rising edge of the digital input.
• The drive loads User parameter set2 on the falling edge of the digital input.
• The User parameter set changes only when the drive is stopped.
-2…-5 = DI2(INV)…DI5(INV) – Defines an inverted digital input DI2…DI5 as a control
for changing User parameter sets.
• See DI1(INV) above.
Group 16: System controls
Code Description Range Resolution Default S
