Actual signals and parameters 257
5305
EFB CTRL PROFILE
0…2 1 0
Selects the communication profile. See section Communication profiles on page 337.
0 = ABB DRV LIM – Operation of Control/Status words conforms to ABB Drives Profile.
1 = DCU PROFILE – Operation of Control/Status words conforms to 32-bit DCU
Profile.
2 = ABB DRV FULL – Operation of Control/Status words conforms to ABB Drives
Profile.
5306
EFB OK MESSAGES
0…65535 1 0
Number of valid messages received by the drive. During normal operation, this number
increases constantly.
5307
EFB CRC ERRORS
0…65535 1 0
Number of messages with a CRC (cyclic redundancy check) error received by the
drive. If the number is high, check CRC calculation for possible errors.
Note: High electromagnetic noise levels generate errors.
5308
EFB UART ERRORS
0…65535 1 0
Number of messages with a character error received by the drive.
5309
EFB STATUS
0…7 1 0
Status of the EFB protocol.
0 = IDLE – EFB protocol is configured, but not receiving any messages.
1 = EXECUT INIT – EFB protocol is initializing.
2 = TIME OUT – A time-out has occurred in the communication between the network
master and the EFB protocol.
3 = CONFIG ERROR – EFB protocol has a configuration error.
4 = OFF-LINE – EFB protocol is receiving messages that are NOT addressed to this
drive.
5 = ON-LINE – EFB protocol is receiving messages that are addressed to this drive.
6 = RESET– EFB protocol is performing a hardware reset.
7 = LISTEN ONLY – EFB protocol is in listen-only mode.
5310…
5320
EFB PAR 10…
EFB PAR 20
0…9999 1 Protocol
dep.
5321
MDB DATA IN 1
0…9999 1 0
Modbus register 40013 - Read only. Supported by STD Modbus only.
5322
MDB DATA IN 2
0…9999 1 0
Modbus register 40014 - Read only. Supported by STD Modbus only.
5323
MDB DATA OUT 1
0…9999 1 0
Modbus register 40080 - Write only. Supported by STD Modbus only.
5324
MDB DATA OUT 2
0…9999 1 0
Modbus register 40081 - Write only. Supported by STD Modbus only.
5325
MDB DATA OUT 13
0…9999 1 0
Modbus register 40082 - Write only. Supported by STD Modbus only.
5326
MDB DATA OUT 4
0…9999 1 0
Modbus register 40083 - Write only. Supported by STD Modbus only.
Group 53: EFB protocol
Code Description Range Resolution Default S
