Actual signals and parameters 259
6405
AL2 SIGNAL BASE
--
Defines the base value from which the percentage distribution is calculated.
Representation and default value depends on the signal selected with parameter 6404
AL2 SIGNAL.
6406
PEAK VALUE
--
Detected peak value of the signal selected with parameter 6401 PVL SIGNAL.
6407
PEAK TIME 1
0 … 65535 d 1 = 1 d 0 d
Date of the peak value detection. Day on which the peak value was detected.
Format: Date if the real time clock is operating. / The number of days elapsed after the
power-on if the real time clock is not used, or was not set.
6408
PEAK TIME 2
00:00:00 … 23:59:58 00:00:00
Time of the peak value detection.
6409
CURRENT AT PEAK
0.0 … 6553.5 A 1 = 0.1 A 0.0 A
Current at the moment of the peak value
6410
UDC AT PEAK
0 … 65535V 1 = 1V 0V
DC voltage at the moment of the peak value
6411
FREQ AT PEAK
0.0 … 6553.5 Hz 1 = 0.1 Hz 0.0 Hz
Output frequency at the moment of the peak value
6412
TIME OF RESET 1
0 … 65535 d 1 = 1 d 0 d
Last reset date of the peak logger and amplitude logger 2. Day of the last reset.
Format: Date if the real time clock is operating. / Number of days elapsed after the
power-on if the real time clock is not used, or was not set.
6413
TIME OF RESET 2
00:00:00 … 23:59:58 00:00:00
Last reset time of the peak logger and amplitude logger 2.
6414
AL1RANGE0TO10
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 0…10% distribution
6415
AL1RANGE10TO20
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 10…20% distribution
6416
AL1RANGE20TO30
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 20…30% distribution
6417
AL1RANGE30TO40
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 30…40% distribution
6418
AL1RANGE40TO50
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 40…50% distribution
6419
AL1RANGE50TO60
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 40…50% distribution
6420
AL1RANGE60TO70
0.0 … 100.0% 1 = 0.1% 0.0%
Amplitude logger 1 (current in percent of nominal current) 40…50% distribution
Group 64: Load analyzer
Code Description Range Resolution Default S
