Fieldbus control 289
5303 EFB BAUD RATE
Defines the
communication speed of
the EIA-485 link in kbits
per second (kbits/s).
1.2 kbits/s
2.4 kbits/s
4.8 kbits/s
9.6 kbits/s
19.2 kbits/s
38.4 kbits/s
57.6 kbits/s
76.8 kbits/s
When this protocol is selected,
the default value for this
parameter is
When this protocol is
selected, the default value
for this parameter is:
38400.
9.6 9.6 4.8
5304 EFB PARITY
Defines the data length,
parity and stop bits to be
used with the EIA-485 link
communication.
The same settings must
be used in all on-line
stations.
0 = 8N1 – 8 data bits, No
parity, one stop bit.
1 = 8N2 – 8 data bits, No
parity, two stop bits.
2 = 8E1 – 8 data bits,
Even parity, one stop bit.
3 = 8O1 – 8 data bits, Odd
parity, one stop bit.
When this
protocol is
selected,
the default
value for
this
parameter
is: 1
When this protocol is selected, the default
value for this parameter is: 0
Sets MS/TP character
format.
Code Description EFB Protocol Reference
Modbus N2 FLN BACnet
