290 Fieldbus control
5305 EFB CTRL PROFILE
Selects the
communication profile
used by the EFB protocol.
0 = ABB DRV LIM –
Operation of
Control/Status Words
conform to ABB Drives
Profile, as used in
ACH400.
1 = DCU PROFILE –
Operation of
Control/Status Words
conform to 32-bit DCU
Profile.
2 = ABB DRV FULL –
Operation of
Control/Status Words
conform to ABB Drives
Profile, as used in
ACH600/800.
When this
protocol is
selected,
the default
value for
this
parameter
is: 0
N/A. When this protocol is selected, the default
value for this parameter is: 0.
Changing the value for this parameter has no
affect on this protocol’s behavior.
5310 EFB PAR10 Not used for
Comm
setup.
Sets them response turnaround time in
milliseconds. When this protocol is selected,
the default value is:
3 msec. 0 msec. 5 msec.
5311 EFB PAR11 Not used for Comm setup. This parameter, together
with parameter 5317, sets
BACnet Device Object
Instance IDs:
For the range 1 to 65,535:
This parameter sets the ID
directly (5317 must be 0).
For example, the following
values set the ID to
49134: 5311 = 49134 and
5317 = 0.
For IDs > 65,335: The ID
equals 5311’s value plus
10,000 times 5317’s
value. For example, the
following values set the ID
to 71234: 5311 = 1234
and 5317 = 7.
5312 EFB PAR12 Not used for Comm setup. This parameter sets the
BACnet Device Object
Max Info Frames Property.
Code Description EFB Protocol Reference
Modbus N2 FLN BACnet
