314 Fieldbus control
Process PID
External PID
FLN process PID report
Point
Subpoint name Data
# Ty pe
15 LAI PRC PID FBCK Each host FLN application (for example, CIS or
Insight) controls both the particular data reported for
each point, and the report format.
16 LAI PRC PID DEV
50 LAO PRC PID GAIN
51 LAO PRC PID ITIM
52 LAO PRC PID DTIM
53 LAO PRC PID DFIL
54 LDO PRC PID SEL
60 LAO INPUT REF1
61 LAO INPUT REF2
82 LAI AI 1 ACTUAL
83 LAI AI 2 ACTUAL
84 LAI AO 1 ACTUAL
FLN external PID report
Point
Subpoint name Data
# Type
55 LAO EXT PID GAIN Each host FLN application (for example, CIS or
Insight) controls both the particular data reported for
each point, and the report format.
56 LAO EXT PID ITIM
57 LAO EXT PID DTIM
58 LAO EXT PID DFIL
62 LAO EXT PID STPT
63 LAI EXT PID FBCK
64 LAI EXT PID DEV
82 LAI AI 1 ACTUAL
83 LAI AI 2 ACTUAL
84 LAI AO 1 ACTUAL
