Fieldbus control 321
32 DECEL TIME 1 Sets the deceleration time for Ramp 1. 2203
33 HANDAUTO
ACT
Indicates whether the drive is in Hand or Auto control
(1 = HAND, 0 = AUTO).
34 ENA.DIS ACT Indicates the status of the Run Enable command,
regardless of its source (1 = ENABLE, 0 = DISABL).
35 ENA.DIS CMD Commanded by FLN to assert the Run Enable
command
(1 = ENABLE, 0 = DISABL).
Parameter 1601 must be set to COMM for FLN to have
this control.
36 FLN LOC ACT Indicates if the drive has been placed in “FLN LOCAL”
mode by commanding either point 68 (FLN LOC CTL) or
point 69 (FLN LOC REF). Commanding either of these
points to FLN (1) “steals” control from its normal source
and places in under FLN control.
Note that the HAND mode of the panel has priority over
FLN local control.
37 FLN CTL SRC Indicates if FLN is a source for control inputs
(1 = YES, 0 = NO).
Note that this status point is true if any of the following
control inputs are from FLN: Run/Stop, Ext1/2 Select or
Run Enable.
38 FLN REF1 SRC Indicates if FLN is the source for speed reference 1
(1 = YES, 0 = NO).
39 FLN REF2 SRC Indicates if FLN is the source for speed reference 2
(1 = YES, 0 = NO).
40 RO1 COMMAND Controls the output state of Relay 1.
Parameter 1401 must be set to COMM for FLN to have
this control (1 = ON, 0 = OFF).
0134, bit 0
41 RO2 COMMAND Controls the output state of Relay 2. Access to relay 2
requires ACS320 option MREL.
Parameter 1402 must be set to COMM for FLN to have
this control (1 = ON, 0 = OFF).
0134, bit 2
42 RO3 COMMAND Controls the output state of Relay 3. Access to relay 3
requires ACS320 option MREL.
Parameter 1403 must be set to COMM for FLN to have
this control (1 = ON, 0 = OFF).
0134, bit 3
43 RO4 COMMAND Controls the output state of Relay 4. Access to relay 4
require ACS320 option MREL.
Parameter 1410 must be set to COMM for FLN to have
this control (1 = ON, 0 = OFF).
0134, bit 4
44,
45
N/A
46 AO1 COMMAND Controls Analog Output 1.
Parameter 1501 must be set to this value for FLN to
have this control.
0135
(COMM
VALUE 1)
47 N/A
FLN Detailed Point Descriptions
Point Description
Drive
Parameter
