340 Fieldbus control
* = Active low
For the 1xxxx registers:
• Additional discrete inputs are added sequentially.
The drive supports the following Modbus function codes for discrete inputs:
3xxxx Mapping – Modbus Inputs. The drive maps the following information to the
3xxxx Modbus addresses called Modbus input registers:
• Any user defined analog inputs.
10016 – Bit 15 N/A FAULT
10017 – Bit 16 Reserved ALARM
10018 – Bit 17 Reserved REQ_MAINT
10019 – Bit 18 Reserved DIRLOCK
10020 – Bit 19 Reserved LOCALLOCK
10021 – Bit 20 Reserved CTL_MODE
10022 – Bit 21 Reserved Reserved
10023 – Bit 22 Reserved Reserved
10024 – Bit 23 Reserved Reserved
10025 – Bit 24 Reserved Reserved
10026 – Bit 25 Reserved Reserved
10027 – Bit 26 Reserved REQ_CTL
10028 – Bit 27 Reserved REQ_REF1
10029 – Bit 28 Reserved REQ_REF2
10030 – Bit 29 Reserved REQ_REF2EXT
10031 – Bit 30 Reserved ACK_STARTINH
10032 – Bit 31 Reserved ACK_OFF_ILCK
10033 DI1 DI1
10034 DI2 DI2
10035 DI3 DI3
10036 DI4 DI4
10037 DI5 DI5
Function Code Description
02 Read input status
Modbus
Ref.
Internal Location
(All Profiles)
(5305 = 0 or 2)
(5305 = 1)
