Start-up 69
The order of tasks presented by the Start-up assistant depends on your entries. The
following task list is typical.
Task name Description
Spin the motor • Prompts for control panel display language selection.
• Prompts for motor data.
• Guides user through rotation check.
Commission drive Prompts for motor data.
References 1 & 2 • Prompts for the source of speed references 1 and 2.
• Prompts for reference limits.
• Prompts for frequency (or speed) limits.
Start/Stop Control • Prompts for the source for start and stop commands.
• Prompts for start and stop mode definition.
• Prompts for acceleration and deceleration times.
Protections • Prompts for current and torque limits.
• Prompts for the use of Run enable and Start enable signals.
• Prompts for the use of emergency stop.
• Prompts for Fault function selection.
• Prompts for Auto reset functions selection.
Constant Speeds • Prompts for the use of constant speeds.
• Prompts for constant speed values.
PID control • Prompts for PID settings.
• Prompts for the source of process reference.
• Prompts for reference limits.
• Prompts for source, limits and units for the process actual value.
• Defines the use of Sleep function.
PID flow • Prompts for the use of flow calculation.
• Prompts for units.
• Prompts for maximum flow.
• Prompts for transmitter signals.
Low Noise Set-up • Prompts for switching frequency.
• Prompts for definition of Flux optimization.
• Prompts for the use of Critical speeds.
Panel Display Prompts for display variable and unit settings.
Timed Functions Prompts for the use of Timed functions.
Outputs • Prompts for the signals indicated through the relay outputs.
• Prompts for signals indicated through the analog output AO1. Sets the
minimum, maximum, scaling and inversion values.
Serial
Communication
• Prompts for communication settings.
• Prompts for control access settings.
