222 Actual signals and parameters
2108 START INHIBIT Sets the Start inhibit function on or off. If the drive is not
actively started and running, the Start inhibit function
ignores a pending start command in any of the following
situations and a new start command is required:
• a fault is reset.
• Run enable signal activates while the start command is
active. See parameter 1601 RUN ENABLE.
• control mode changes from local to remote.
• external control mode switches from EXT1 to EXT2 or
from EXT2 to EXT1.
OFF
OFF Disabled 0
ON Enabled 1
2109 EMERG STOP
SEL
Selects the source for the external emergency stop
command.
The drive cannot be restarted before the emergency stop
command is reset.
Note: The installation must include emergency stop devices
and any other safety equipment that may be needed.
Pressing the stop key on the drive’s control panel does
NOT:
• generate an emergency stop of the motor
• separate the drive from dangerous potential.
NOT SEL
NOT SEL Emergency stop function is not selected 0
DI1 Digital input DI1. 1 = stop along the emergency stop ramp.
See parameter 2208 EMERG DEC TIME. 0 = emergency
stop command reset.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DI1(INV) Inverted digital input DI. 0 = stop along the emergency stop
ramp. See parameter 2208 EMERG DEC TIME. 1 =
emergency stop command reset
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
2110 TORQ BOOST
CURR
Defines the maximum supplied current during torque boost.
See parameter 2101 START FUNCTION.
100%
15…300% Value in percent 1 = 1%
2111 STOP SIGNAL
DLY
Defines the stop signal delay time when parameter 2102
STOP FUNCTION is set to SPEED COMP.
0ms
0…10000 ms Delay time 1 = 1 ms
All parameters
No. Name/Value Description Def/FbEq
