Fault tracing 349
0101 SERF CORRUPT
(FF55)
0307 bit 14
Drive internal error Write down fault code and contact
your local ABB representative.
0103 SERF MACRO
(FF55)
0307 bit 14
0201 DSP T1
OVERLOAD
(6100)
0307 bit 13
0202 DSP T2
OVERLOAD
(6100)
0307 bit 13
0203 DSP T3
OVERLOAD
(6100)
0307 bit 13
0204 DSP STACK
ERROR
(6100)
0307 bit 12
0206 CB ID ERROR
(5000)
0307 bit 11
1000 PAR HZRPM
(6320)
0307 bit 15
Incorrect
speed/frequency limit
parameter setting
Check parameter settings. Check that
following applies:
• 2001 MINIMUM SPEED <
2002 MAXIMUM SPEED
• 2007 MINIMUM FREQ <
2008 MAXIMUM FREQ
• 2001 MINIMUM SPEED /
9908 MOTOR NOM SPEED,
2002 MAXIMUM SPEED /
9908 MOTOR NOM SPEED,
2007 MINIMUM FREQ /
9907 MOTOR NOM FREQ and
2008 MAXIMUM FREQ /
9907 MOTOR NOM FREQ are
within range.
1003 PAR AI SCALE
(6320)
0307 bit 15
Incorrect analog input
AI signal scaling
Check parameter group 13 ANALOG
INPUTS settings. Check that following
applies:
• 1301 MINIMUM AI1 <
1302 MAXIMUM AI1
• 1304 MINIMUM AI2 <
1305 MAXIMUM AI2.
CODE FAULT CAUSE WHAT TO DO
