90 Control panels
Initially, the panel is in the Output mode, where you can
start, stop, change the direction, switch between local and
remote control, modify the reference value and monitor up
to three actual values.
To do other tasks, go first to the Main menu and select the
appropriate mode on the menu. The status line (see
section Status line on page 89) shows the name of the
current menu, mode, item or state.
How to do common tasks
The table below lists common tasks, the mode in which you can perform them and
the page number where the steps to do the task are described in detail.
Task Mode Page
How to get help Any 91
How to find out the panel version At power up 91
How to adjust the display contrast Output 94
How to switch between local and remote control Any 92
How to start and stop the drive Any 93
How to change the direction of the motor rotation Output 93
How to set the speed, frequency or torque reference Output 94
How to change the value of a parameter Parameters 95
How to select the monitored signals Parameters 96
How to do guided tasks (specification of related parameter sets)
with assistants
Assistants 98
How to view and edit changed parameters Changed
parameters
100
How to view faults Fault logger 101
How to reset faults and alarms Output, Fault 335
How to show/hide the clock, change date and time formats, set the
clock and enable/disable automatic clock transitions according to
the daylight saving changes
Time and date 102
How to copy parameters from the drive to the control panel Parameter
backup
105
How to restore parameters from the control panel to the drive Parameter
backup
105
How to view backup information Parameter
backup
106
How to edit and change parameter settings related to I/O terminals I/O settings 107
DIR
MENU
00:00
LOC
49.1Hz
49 1 Hz.
05 A.
10 7 %.
PARAMETERS
ASSISTANTS
CHANGED PAR
EXIT
ENTER
00:00
LOC
MAIN MENU 1
