II K 4-48
Overview of Software
ParNo. Parameter name and significance Min Max Default Unit (1)
custom.
setting
Grp 2 Operation Mode (continued)
2.04
Wizard
Eme Stop Mode
Selection of the desired operating response to an
Eme Stop command (controller blocking)
0 = Ramp
Motor decelerates in acc. to
Eme Stop Ramp (5.11)
.
If
Zero Speed Lev (5.15)
is reached Main Contactor
is switched off.
1 = Torque Lim
Motor decelerates in acc. to torque limit. If
Zero
Speed Lev (5.15)
is reached Main Contactor is swit-
ched off.
2 = Coast
Main Contactor is switched off. Motor coasts to zero
speed.
Eme Stop
command works
always
speed controlled
independent on current controller mode
Cur Contr Mode
(3.14)
settings. Response time of deceleration by
Ramp
or
Torque Lim
depends on optimization of speed con-
troller. Therefore the speed controller must be adjusted.
If
Alt
ernative
Par
ameterset is
Sel
ected
(5.21)
for speed
controller it’s also valid for Eme Stop command. Only
Coast
is independend on speed controller settings.
Disable Bridge 1 (9.19)
and
Disable Bridge 2 (9.20)
are
also effective during
Eme
Stop Mode
. If a bridge is dis-
abled (locked) it’s not possible to brake the drive by using
Ramp
or
Torque Lim
. Use external wiring to make sure
that bridges are enabled for braking down the drive if
necessary.
External
current / torque limitation via
analog input
or
serial communication
doesn’t have any effect to
Eme
Stop Mode
.
Without
serial communication:
Emergency Stop
from terminal is
always
valid.
Coast
from terminal will not be valid until it has been
activated using the
Coast (9.04)
parameter.
With
serial communication:
Cmd Location (2.02) = Bus:
Emergency Stop
and
Coast
via the bus are “1” active
and must be provided.
Emer
Stop
via bus
are
AND
ed; both must be provided. When
Coast
from terminal has been activated in parameter Coast
(9.04)
, then
terminal
and
Coast via bus
are
AND
ed;
both must be provided.
Cmd Location (2.02) = Key:
If the bus is functioning properly, the behaviour is as
described in
Cmd Location (2.02) = Bus
. If the bus is
malfunctioning, the
Emergency Stop
and
Coast via bus
functions will be suppressed; only the
terminal
remains
active. This enables the drive to be controlled from the
terminal without any trouble.
020Text
x
(1) no changes possible if the drive is in ON-status
