II K 4-49
Overview of Software
ParNo. Parameter name and significance Min Max Default Unit (1)
custom.
setting
Grp 2 Operation Mode (continued)
2.05
Signal
Main Ctrl Word
The Main Ctrl Word maps the control bits of the
drive. This parameter indicates the control bits of
the terminal block or of the bus communication. The
allocation is identical with the control word of field
bus communication.
Bit hex definition (log. „1“state)
00 0001 On
01 0002 Coast (not)
02 0004 Eme Stop (not)
03 0008 Run
04 0010 -
05 0020 -
06 0040 -
07 0080 Reset
08 0100 Jog 1
09 0200 Jog 2
10 0400 -
11 0800 MCW Bit 11
12 1000 MCW Bit 12
13 2000 MCW Bit 13
14 4000 MCW Bit 14
15 8000 MCW Bit 15
---hex
2.06
Signal
Main Stat Word
The Main Stat Word maps the status bits of drive
and status logic. The allocation is identical with the
status word of field bus communication.
Bit hex definition (log. "1" state)
00 0001 Rdy On
01 0002 Rdy Running
02 0004 Running
03 0008 Fault
04 0010 Coast Act (not)
05 0020 Eme Stop Act (not)
06 0040 -
07 0080 Alarm
08 0100 At Setpoint
09 0200 Remote
10 0400 Above Limit 1 (> 5.16)
11 0800 MSW Bitt 11 Ass (6.22)
12 1000 MSW Bitt 12 Ass (6.23)
13 2000 MSW Bitt 13 Ass (6.24)
14 4000 MSW Bitt 14 Ass (6.25)
15 8000 DDCS Breakdown
---hex
(1) no changes possible if the drive is in ON-status
