Commissioning
© 2006 ABB STOTZ-KONTAKT GmbH 190
ABB i-bus
®
EIB / KNX
After selecting the option new group address, the associated dialog window
Add group addresses is activated.
Fig. 178: Dialog window: “Group member, Add group addresses”
The main group, middle group and the subgroup are created in sequence via
drag & drop.
Fig. 179: Parameter window: “Group member, Create new main group, middle group and subgroup”
Fig. 180: Dialog window: “Group member, Main group, middle group and subgroup created”
