ABB i-bus EIB User Manual

ABB i-bus
®
KNX
Commissioning
FCA/S 1.x.x.1 | 2CDC508134D0202 225
No.
Functionality
communication object name
Data type
Flags
66
Automatic ON/OFF
Fan E, F, G
1 bit
DPT 1.003
C, W
This communication object is enabled if the parameter Enable automatic operation has been selected with the option Yes in
Parameter window E, F, G: Fan (One-level), p. 149.
If automatic mode is enabled, it will be activated on this communication object with the value 1 after a download, ETS reset or
via a telegram. Automatic mode is switched off if a signal is received on a “manual communication object”.
Manual communication objects are:
 Fan: Switch speed
 Fan: Switch speed x (x = 1, 2 or 3)
 Fan: Fan speed up/down
 Fan: Limitation x (x = 1, 2, 3 or 4)
During one of the four limitations or forced operation, automatic mode remains active but operates only within the allowed
limits.
If the value 1 is set in the parameter:
Telegram value:
0 = Automatic operation OFF
1 = Automatic operation ON
If the value 0 is set in the parameter:
Telegram value:
0 = Automatic operation ON
1 = Automatic operation OFF
67
Status Automatic
Fan E, F, G
1 bit
DPT 1.003
C, R, W
This communication object is enabled if the parameter Enable communication object "Status Automatic" 1-bit has been
selected with the option Yes in Parameter window Status messages (single speed), p. 152.
You can parameterize whether the communication object value is updated but not sent, sent on request, or only sent when
changed.
The communication object indicates the status of automatic operation.
Telegram value:
0 = Inactive
1 = Activated
