ABB i-bus EIB User Manual

ABB i-bus
®
KNX
Commissioning
226 2CDC508134D0202 | FCA/S 1.x.x.1
No.
Functionality
communication object name
Data type
Flags
68
Status byte fan
Fan E, F, G
1-byte
Non DPT
C, R, T
This communication object is enabled if the parameter Enable communication object "Status byte fan" 1-byte has been
selected with the option Yes in Parameter window Status messages (single speed), p. 152.
The operating state of the fan can be displayed or sent on the bus via this communication object. You can parameterize
whether the communication object value is updated but not sent, sent on request, or only sent when changed.
Telegram values:
Bit sequence
76543210
Bit 7:
Forced operation
0:
1:
Inactive
Active
Bit 6:
Limitation 1
0:
1:
Inactive
Active
Bit 5:
Limitation 2
0:
1:
Inactive
Active
Bit 4:
Limitation 3
0:
1:
Inactive
Active
Bit 3:
Limitation 4
0:
1:
Inactive
Active
Bit 2:
Thermostat fault
0:
1:
Inactive
Active
Bit 1:
Automatic
0:
1:
Inactive
Active
Bit 0:
Actuating value
0:
1:
Control value A
Control value C
For further information see: Status byte fan, p. 258
