Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 109
Staircase lighting (STAIRC LIGHT)
A timer that automatically resets the output to 0 (false) after a specified time has elapsed.
Inputs
No.
DPT
Abbr.
Name
Visible
Description
1
1 bit
Imp
Trigger
Always
2 4 bytes unsigned T On-time Parametrizable
Value in seconds;
according to KNX DPT
13.100
3 1 bit Z Reset Parametrizable
1 = yes
0 = no
Outputs
No.
DPT
Abbr.
Name
Invertible
Visible
Description
1 1 bit A Output Yes Always
1 (true), as long as the timer is
running
Input parameters
Name
Value
Visible
Description
On-time Checkbox Always
Activates input T (On-
time)
Unsigned integer in [s]
If the checkbox is
cleared
Reset
Checkbox
Always
Activates input Z (Reset)
Checkbox 2
If Checkbox 1 is
cleared
If the Reset input receives
a value, the timer resets to
0
If the On-time checkbox is selected, the time value field is not visible. The same applies to the Reset
checkbox.
