ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
152 2CDC508198D0211 Rev. A | AC/S 1.x.1
WebUI to KNX with update
A value entered on the web user interface is sent by the group object using this template. A value received
from the KNX bus updates the value on the web user interface. This value is also output on the ASM
output socket for linking to other modules.
The settings for the ASM socket, web user interface, KNX and BACnet are set automatically as follows:
ASM socket:
Output
WebUI:
Display + Set
KNX:
Input + output
BACnet:
None
Main data point type
Data point type
Definition of the data point type that is transferred between the interfaces.
You will find further information on the data point types in chapter 4.7 Data point types
.
Use value after restart
Options:
Last value
Initial value
This parameter specifies which value is output on the ASM output socket after starting the application
controller until a new value is received in the group object.
• Last value: The last value before device start is saved and reused. The value parameterized further
down in Initial value is used after the first download of the module to the application controller.
• Initial value: The value described further down in Initial value is used.
