ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 207
Object function
Name (can be changed
separately)
Data type
Flags
Input: On/Off confirm (slave)
Room
1 bit
DPT 1.001
C, W, T, U
The module has this group object if the Display+set (slave) option is selected for the Controller On/Off parameter.
This group object is used for synchronization between the Room ASM (slave) and the room thermostat (master). For this
purpose the group object must be connected to the controller's (master's) group object of the same name.
In this group object the room thermostat (master) confirms to the Room ASM (slave) whether it is currently switched on or off
Telegram value: 0 = Off
1 = On
Output: On/Off request (slave)
Room
1 bit
DPT 1.001
C, T
The module has this group object if the
Display+set (slave)
option is selected for the
Controller On/Off
parameter.
This group object is used for synchronization between the Room ASM (slave) and the room thermostat (master). For this
purpose the group object must be connected to the controller's (master's) group object of the same name.
The Room ASM sends the switch on or switch off request to the controller in this group object.
Telegram value: 0 = Off
1 = On
Input: Heating/cooling operating type Room 1 bit
DPT 1.100
C, W, T, U
The module has this group object if the
Display
option is selected for the
Heating/cooling operating type
parameter.
Input for the connection of the heating/cooling operating type from the room thermostat.
Telegram value:
0 = Cooling
1 = Heating
