ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 187
Controller On/Off
This parameter specifies whether the On/Off status of the room thermostat received via KNX is only to be
displayed on the web user interface, or it can also be changed by the user. The current value is output on
the ASM output socket and in a BACnet object.
• None: The On/Off status of the room thermostat is not used in the module and can therefore not be
displayed on the web user interface.
• Display: The On/Off status of the room thermostat from KNX is displayed on the web user interface.
The current value is output on the ASM output socket and in a BACnet object
• Display+set (slave): The room thermostat can be switched on or off via the web user interface. The
command is sent via KNX to the room thermostat. The current value is output on the ASM output
socket and in a BACnet object.
This setting functions only with ABB and Busch-Jaeger devices with the old master/slave interface
Heating/cooling operating type
This parameter specifies whether the heating/cooling operating type from the room thermostat received via
KNX is only to be displayed on the web user interface, or it can also be changed by the user. The current
value is output on the ASM output socket and in a BACnet object.
• None: The heating/cooling operating type is not used in the module; this operating type is therefore
not displayed on the web user interface.
• Display: The heating/cooling operating type from KNX is displayed on the web user interface. The
current value is output on the ASM output socket and in a BACnet object.
• Display+set (slave): The heating/cooling operating type can be changed on the web user interface and
is sent via KNX. The current value is output on the ASM output socket and in a BACnet object.
This setting functions only with ABB and Busch-Jaeger devices with the old master/slave interface
