Parameters
214 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object function
Name (can be changed
separately)
Data type
Flags
Input: Fan coil unit, additional-stage heating
Room
1 bit DPT 1.001
1 byte DPT 5.001
C, W, T, U
Input for the control value for the additional-stage heating on the fan coil unit.
The data point type for the group object is dependent on the settings in the module:
• If any option except None is selected for the Fan coil unit parameter and the On/Off option is selected for the
Fan coil unit,
additional-stage heating parameter:
DPT 1.001
Telegram value 0 = Off, 1 = On
• If any option except None is selected for the Fan coil unit parameter and the 0…100 % option is selected for the
Fan coil
unit, additional-stage heating parameter:
DPT 5.001
Telegram value 0…100 %
Input: Fan coil unit, fresh air damper
Room
1 bit DPT 1.019
1 byte DPT 5.001
C, W, T, U
Input for the position of the fresh air damper.
The data point type for the group object is dependent on the settings in the module:
• If any option except None is selected for the Fan coil unit parameter and the Open/Closed option is selected for the
Fan
coil unit, fresh air damper parameter:
DPT 1.019
Telegram value 0 = Closed, 1 = Opened
• If any option except None is selected for the Fan coil unit parameter and the 0…100 % option is selected for the
Fan coil
unit, fresh air damper parameter:
DPT 5.001
Telegram value 0…100 %
Input: Fan coil unit, dew point sensor Room 1 bit
DPT 1.001
C, W, T, U
The module has this group object if any option except None is selected for the Fan coil unit parameter and the Yes option is
selected for the Fan coil unit, dew point sensor parameter.
Input for the signal value from the dew point sensor in the fan coil unit.
Telegram value: 0 = Off
1 = On
