Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 215
Object function
Name (can be changed
separately)
Data type
Flags
Input: Fan coil unit, level sensor
Room
1 bit
DPT 1.001
C, W, T, U
The module has this group object if any option except None is selected for the Fan coil unit parameter and the Yes option is
selected for the Fan coil unit, level sensor parameter.
Input for the signal value from the level sensor in the fan coil unit.
Telegram value:
0 = Off
1 = On
Input: Radiator, valve
Room
1 bit DPT 1.001
1 byte DPT 5.001
C, W, T, U
Input for the position (control value) of the radiator valve.
The data point type for the group object is dependent on the settings in the module:
• If the On/Off option is selected for the Radiator
parameter:
DPT 1.001
Telegram value 0 = Off, 1 = On
• If the 0…100 % option is selected for the Radiator
parameter:
DPT 5.001
Telegram value 0…100 %
Input: Floor heating, valve
Room
1 bit DPT 1.001
1 byte DPT 5.001
C, W, T, U
Input for the position (control value) of the floor heating valve.
The data point type for the group object is dependent on the settings in the module:
• If the On/Off option is selected for the Floor heating
parameter:
DPT 1.001
Telegram value 0 = Off, 1 = On
• If the 0…100 % option is selected for the Floor heating
parameter:
DPT 5.001
Telegram value 0…100 %
