ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
216 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object function
Name (can be changed
separately)
Data type
Flags
Input: Floor temperature sensor
Room
2 bytes
DPT 9.001
C, W, T, U
The module has this group object if the On/Off option or the 0…100 % option is selected for the Floor heating parameter and
the Yes option is selected for the Floor temperature sensor parameter.
Input for the floor temperature.
Telegram value:
-273...670760 °C
Input: Cooling ceiling, valve Room 1 bit DPT 1.001
1 byte DPT 5.001
C, W, T, U
Input for the position (control value) of the cooling ceiling valve.
The data point type for the group object is dependent on the settings in the module:
• If the On/Off option is selected for the Cooling ceiling
parameter:
DPT 1.001
Telegram value 0 = Off, 1 = On
• If the 0…100 % option is selected for the Cooling ceiling
parameter:
DPT 5.001
Telegram value 0…100 %
Input: Cooling ceiling, dew point alarm sensor
Room
2 bytes
DPT 9.001
C, W, T, U
The module has this group object if the On/Off option or the 0…100 % option is selected for the Cooling ceiling parameter and
the Yes option is selected for the Cooling ceiling, dew point alarm sensor parameter.
Input for the signal value from the dew point sensor in the cooling ceiling.
Telegram value:
-273...670760 °C
Input: Split unit, On/Off Room 1 bit
DPT 1.001
C, W, T, U
The module has this group object if the Yes option is selected for the Split unit parameter.
Input for the operating status of the split unit.
Telegram value:
0 = Off
1 = On
