Object function
Name (can be changed
separately)
Data type
Flags
Input: Split unit, fan speed
Room
1 byte
DPT 5.001
C, W, T, U
The module has this group object if the Yes option is selected for the Split unit parameter.
Input for the fan speed in the split unit.
Telegram value: 0…100%
Input: Split unit, status
Room
1 byte
DPT 20.105
C, W, T, U
The module has this group object if the
Yes
option is selected for the
Split unit
parameter.
Input for the status of the split unit.
Telegram value: 0 = Auto
1 = Heat
2 = Morning Warmup
3 = Cool
4 = Night Purge
5 = Precool
6 = Off
7 = Test
8 = Emergency Heat
9 = Fan only
0A = Free Cool
0B = Ice
0C = Maximum Heat Mode
0D = Economic Heat/Cool Mode
0E = Dehumidification
0F = Calibration Mode
10 = Emergency Cool Mode
11 = Emergency Steam Mode
14 = No Dem
