ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 265
Object name
Data type
Valve override disable/enable DPT 1.003
The module has this output socket if the
3-way valve (mixing valve)
option or the
2-way valve
option is selected for the
Valve
type parameter and the Yes option is selected for the Valve override disable/enable parameter.
Outputs whether the override of the heating distribution circuit's valve is active or inactive.
Signal value: 0 = Disabled
1 = Enabled
Valve override control value
DPT 5.001
The module has this output socket if the 3-way valve (mixing valve) option or the 2-way valve option is selected for the Valve
type parameter and the Yes option is selected for the Valve override disable/enable parameter.
Outputs the value used to override the heating distribution circuit's valve if the override is active
Signal value:
0…100 %
Status Valve purge
DPT 1.011
The module has this output socket if the 3-way valve (mixing valve) option or the 2-way valve option is selected for the Valve
type parameter and the Yes option is selected for the Status Valve purge parameter.
Outputs the status as to whether the heating distribution circuit controller is actually undertaking a valve purge. This value is
received from the heating distribution circuit controller linked via the related module group object.
Signal value:
0 = Inactive
1 = Active
Pump A operating status (Off/On)
DPT 1.011
The module has this output socket if the Yes option is selected for the Pump display operating status parameter.
Outputs the operating status (Off/On) provided by the pump. On pumps with their own control, this operating status can differ
from the operating status of the heating distribution circuit controller.
Signal value: 0 = Inactive
1 = Active
Pump A relay status DPT 1.001
Outputs the status of the pump from the heating distribution circuit controller.
Signal value:
0 = Off
1 = On
