ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
278 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Object type
Unit
COV send
condition
Heating distribution circuit: Outside temperature
Analog value
°C (62)
1.0
This module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter and the
Calculated weather compensated option is selected for the Supply setpoint temperature source parameter.
Outputs the current outside temperature that is used by the module for the calculation.
Signal value: -273...670760 °C
Heating distribution circuit: Supply setpoint temperature override status
Binary value
-
-
This module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter and the
ASM input socket option, BACnet input object option or the Calculated weather compensated option is selected for the Supply
setpoint temperature source parameter.
Outputs whether the supply setpoint temperature has been overridden via the web user interface.
Signal value:
0 = Not overridden
1 = Overridden
Heating distribution circuit: Supply setpoint temperature External
specification
Analog value
°C (62)
1.0
This module has this BACnet input object if the Yes option is selected for the Supply temperature control parameter and the
ASM input socket option is selected for the Supply setpoint temperature source parameter.
Outputs the supply setpoint temperature specified via the ASM input socket. This status does not take into account any
possible override of the supply setpoint temperature via the web user interface.
Signal value: -273...670760 °C
Heating distribution circuit: Operation mode
Positive integer
value
No unit
(95)
1.0
This module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter, the
Calculated weather compensated option is selected for the Supply setpoint temperature source parameter and the Based on
Scheduler option is selected for the Economy mode parameter.
Outputs the operating mode that is to be used as the basis for the calculation of the supply setpoint temperature.
Signal value:
1 = Comfort
2 = Standby
3 = Economy
4 = Building Protection
