ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 321
Object function
Name (can be changed separately)
Data type
Flags
Input: Pump operating status (Off/On) Heat generator 1 bit
DPT 1.011
C, W, T
The module has this group object if the Yes option is selected for the Pump display operating status parameter.
Input for the operating status (Off/On) provided by the pump.
Telegram value: 0 = Inactive
1 = Active
Input: Pump fault Heat generator 1 bit
DPT 1.011
C, W, T
The module has this group object if the
Yes
option is selected for the
Pump display pump fault status
parameter.
Input for the fault status provided by the pump.
Telegram value: 0 = Inactive
1 = Active
Input: Pump repair switch status Heat generator 1 bit
DPT 1.011
C, W, T
The module has this group object if the Yes option is selected for the Display pump repair switch status parameter.
Input for the contact position provided by the pump repair switch.
Telegram value:
0 = Inactive
1 = Active
