Parameters
350 2CDC508198D0211 Rev. A | AC/S 1.x.1
Output sockets
Object name Data type
Valve control value
DPT 5.001
The module has this output socket if the 3-way valve (mixing valve) option or the 2-way valve option is selected for the Valve
type parameter.
Outputs the valve control value for the cooling distribution circuit. This value is received from the cooling distribution circuit
controller linked via the related module group object
Signal value: 0…100%
Supply temperature
DPT 9.001
Outputs the current supply temperature that is received via the related group object.
Signal value: -273...670760 °C
Return temperature
DPT 9.001
Outputs the current return temperature that is received via the related group object.
Signal value:
-273...670760 °C
Control On/Off
DPT 1.001
The module has this output socket in the following conditions:
• If the Yes option is selected for the Supply temperature control parameter and the Yes option is selected for the
Enable
cooling circuit control based on ASM input socket parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
Outputs the status of the control that is sent to the cooling distribution circuit controller via the related group object. The state
is dependent on the Enable cooling circuit control based on ASM input socket and Switch off if no room demand parameters.
Signal value: 0 = Off
1 = On
