Parameters
360 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object function
Name (can be changed separately)
Data type
Flags
Input: Pump B operating status (Off/On) Cooling distribution circuit 1 bit
DPT 1.011
C, W, T
The module has this group object if the Yes option is selected for the Double pump parameter and the Yes option is selected
for the Pump display operating status parameter.
Input for the operating status (Off/On) provided by the second pump. On pumps with their own control, this operating status
can differ from the operating status of the cooling distribution circuit controller.
Telegram value:
0 = Inactive
1 = Active
Input: Pump B relay status
Cooling distribution circuit
1 bit
DPT 1.001
C, W, T
The module has this group object if the Yes option is selected for the Double pump parameter.
Input for the status of the second pump from the cooling distribution circuit controller.
Telegram value: 0 = Off
1 = On
Output: Control On/Off
Cooling distribution circuit
1 bit
DPT 1.001
C, R, T
The module has this group object in the following conditions:
• If the Yes option is selected for the Supply temperature control parameter and the Yes option is selected for the
Enable
cooling circuit control based on ASM input socket parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
The cooling distribution circuit controller is switched on/off via this group object based on the calculations in the module.
Telegram value:
0 = Off
1 = On
