ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
362 2CDC508198D0211 Rev. A | AC/S 1.x.1
BACnet input objects
Object name Object type Unit COV send
condition
Cooling distribution circuit: Supply setpoint temperature External
specification
Analog value °C (62) -
This module has this BACnet input object if the Yes option is selected for the Supply temperature control parameter and the
BACnet input object option is selected for the Supply setpoint temperature source parameter.
Input for the specification of the supply setpoint temperature. The value is sent by the module to the cooling distribution circuit
controller via the related group object. This supply setpoint temperature specified via BACnet can be overridden manually on
the web user interface.
Signal value: -273...670760 °C
BACnet output objects
Object name
Object type
Unit
COV send
condition
Cooling distribution circuit: Return temperature
Analog value
°C (62)
1.0
Outputs the current return temperature that is received via the related group object.
Signal value: -273...670760 °C
Cooling distribution circuit: Supply temperature
Analog value
°C (62)
1.0
Outputs the current supply temperature that is received via the related group object.
Signal value: -273...670760 °C
Cooling distribution circuit: Supply setpoint temperature status
Analog value
°C (62)
1.0
The module has this BACnet output object if the
Yes
option is selected for the
Supply temperature control
parameter.
Outputs the current supply setpoint temperature as is sent by this module to the cooling distribution circuit controller via the
related group object. The supply setpoint temperature output here is, depending on the settings, either calculated by this
module based on the outside temperature, or specified via an ASM input socket or BACnet and also takes into account any
possible override of the supply setpoint temperature via the web user interface.
Signal value:
-273...670760 °C
