ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 363
Object name
Object type
Unit
COV send
condition
Cooling distribution circuit: Outside temperature
Analog value
°C (62)
1.0
This module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter and the
Calculated weather compensated option is selected for the Supply setpoint temperature source parameter.
Outputs the current outside temperature that is used by the module for the calculation.
Signal value: -273...670760 °C
Cooling distribution circuit: Supply setpoint temperature override status
Binary value
-
-
This module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter and the
ASM input socket option, BACnet input object option or the Calculated weather compensated option is selected for the Supply
setpoint temperature source parameter.
Outputs whether the supply setpoint temperature has been overridden via the web user interface.
Signal value:
0 = Not overridden
1 = Overridden
Cooling distribution circuit: Supply setpoint temperature External
specification
Analog value
°C (62)
1.0
This module has this BACnet input object if the Yes option is selected for the Supply temperature control parameter and the
ASM input socket option is selected for the Supply setpoint temperature source parameter.
Outputs the supply setpoint temperature specified via the ASM input socket. This status does not take into account any
possible override of the supply setpoint temperature via the web user interface.
Signal value: -273...670760 °C
Cooling distribution circuit: Control On/Off
Binary value
-
-
The module has this BACnet output object in the following conditions:
• If the Yes option is selected for the Supply temperature control parameter and the Yes option is selected for the
Enable
cooling circuit control based on ASM input socket parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
Outputs the status (Off/On) of the control that is sent to the cooling distribution circuit controller via the related group object.
The state is dependent on the Enable cooling circuit control based on ASM input socket and Switch off if no room demand
functions as well as override via the web user interface.
Signal value:
0 = Off
1 = On
