BACnet output objects
Object name Object type Unit COV send
condition
Chiller: Return temperature
Analog value
°C (62)
1.0
Outputs the current return temperature that is received via the related group object.
Signal value:
-273...670760 °C
Chiller: Supply temperature Analog value °C (62) 1.0
Outputs the current supply temperature that is received via the related group object.
Signal value:
-273...670760 °C
Chiller: Supply setpoint temperature status Analog value °C (62) 1.0
The module has this BACnet output object if the
Yes
option is selected for the
Supply temperature control
parameter.
Outputs the current supply setpoint temperature as is sent by this module to the chiller via the related group object. The supply
setpoint temperature output here is, depending on the settings, either calculated by this module based on the outside
temperature, or specified via an ASM input socket or BACnet and also takes into account any possible override of the supply
setpoint temperature via the web user interface.
Signal value:
-273...670760 °C
Chiller: Outside temperature Analog value °C (62) 1.0
This module has this BACnet output object if the
Yes
option is selected for the
Supply temperature control
parameter and the
Calculated weather compensated option is selected for the Supply setpoint temperature source parameter.
Outputs the current outside temperature that is used by the module for the calculation.
Signal value:
-273...670760 °C
Chiller: Supply setpoint temperature override status Binary value - -
This module has this BACnet output object if the
Yes
option is selected for the
Supply temperature control
parameter and the
ASM input socket option, BACnet input object option or the Calculated weather compensated option is selected for the Supply
setpoint temperature source parameter.
Outputs whether the supply setpoint temperature has been overridden via the web user interface.
Signal value: 0 = Not overridden
1 = Overridden
