ABB i-bus
®
KNX
Parameters
466 2CDC508198D0211 Rev. A | AC/S 1.x.1
7.20.3 Sockets
Overview of the ASM sockets for linking to other modules:
Type Object name Data type
Input
Trend1
Configuration-dependent
Input Trend2 Configuration-dependent
Input Trend3 Configuration-dependent
Input Trend4 Configuration-dependent
Input
Trend5
Configuration-dependent
Input sockets
Object name
Data type
Trend1
Configuration-dependent
This input socket is always available.
Input for recorded value 1.
Signal value:
Configuration-dependent
Trend2
Configuration-dependent
The module has this input socket if the
2
option or greater is selected for the
Number of trends
parameter.
Input for recorded value 2.
Signal value: Configuration-dependent
Trend3
Configuration-dependent
The module has this input socket if the 3 option or greater is selected for the Number of trends parameter.
Input for recorded value 3.
Signal value:
Configuration-dependent
Trend4 Configuration-dependent
The module has this input socket if the 4 option or greater is selected for the Number of trends parameter.
Input for recorded value 4.
Signal value: Configuration-dependent
Trend5
Configuration-dependent
The module has this input socket if the 5 option is selected for the Number of trends parameter.
Input for recorded value 5.
Signal value: Configuration-dependent
