ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 83
Marker input (MARKER IN)
Markers are used for distant links. Links between worksheets are also possible.
A marker input is logically linked to a marker output; set the parameters for the connection in the
Properties window.
A marker input can only be linked to one marker output!
Outputs
No.
DPT
Abbr.
Name
Visible
Description
1
Any
O
Output
Always
Parameters
Name
Value
Visible
Description
Linked to
List of all MARKER
OUTs
Always
Selects the MARKER OUT to be linked to the
MARKER IN
Marker output (MARKER OUT)
Markers are used for distant links. Links between worksheets are also possible.
A marker output is logically linked to one or more marker inputs; set the parameters for the connection in
the properties window.
Inputs
No.
DPT
Abbr.
Name
Visible
Description
1
Any
I
Input
Always
Parameters
Name
Value
Visible
Description
Linked to
List of all MARKER
INs
Always
Selects the MARKER IN to be linked to the
MARKER OUT
