NoteArt. no.Equipment
DSQC10043HAC045973-001AnybusCC DeviceNet slave
fieldbus adapter
DeviceNet communication is de-
scribed in Application manu-
al - DeviceNet Anybus Slave.
The contents are described in
section Standard toolkit, IRC5 on
page 207.
Standard toolkit
References
NoteArt. no.Equipment
Contains information on how to
configure the system for Ether-
net/IP Fieldbus Adapter DSQC 669.
3HAC050997-001Application manual - EtherNet/IP
Anybus Adapter
Contains information on how to
configure the system for PROFIB-
US Fieldbus Adapter DSQC 667.
3HAC050965-001Application manual - PROFIBUS
Anybus Device
Contains information on how to
configure the system for
PROFINET Fieldbus Adapter
DSQC 688.
3HAC050968-001Application manual - PROFINET
Anybus Device
Contains information on how to
configure the system for DeviceNet
Fieldbus Adapter DSQC1004.
3HAC050993-001Application manual - DeviceNet
Anybus Slave
See Circuit diagrams
on page 217.
Circuit diagram
Removal
The following procedure details how to remove the fieldbus adapter from the
computer unit.
Note/IllustrationAction
DANGER
Before commencing any work inside the
cabinet, please observe the safety inform-
ation in section DANGER - Make sure that
the main power has been switched off! on
page 33.
1
ELECTROSTATIC DISCHARGE
(ESD)
The unit is sensitive to ESD. Before hand-
ling the unit please observe the safety in-
formation in section WARNING - The unit
is sensitive to ESD! on page 34
2
See Removing the controller cover on
page 89.
Remove the cover of the cabinet.3
See Replacement of computer unit on
page 138.
Remove the computer unit.4
Continues on next page
Product manual - IRC5 Compact 155
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
4 Repair
4.9 Replacement of fieldbus adapter in the computer unit
Continued
