Refitting
Use this procedure to refit the Ethernet switch.
Action
DANGER
Before commencing any work inside the cabinet, please observe the safety information
in section DANGER - Make sure that the main power has been switched off! on page 33.
1
ELECTROSTATIC DISCHARGE (ESD)
The unit is sensitive to ESD. Before handling the unit please read the safety information
in the section WARNING - The unit is sensitive to ESD! on page 34
2
Refit the Ethernet switch.3
Refit the safety board and secure it with the attachment screws.4
Refit the safety board unit and secure it with the attachment screws.5
Reconnect all connectors to the Ethernet switch, Remote Service box, and safety
board.
6
Refit the cabinet cover.7
Perform the function tests in section Function tests on page 118 to verify that the safety
features work properly.
8
186 Product manual - IRC5 Compact
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
4 Repair
4.18 Replacement of Ethernet switch
Continued
