Rinse the filter ring (81265) with water and mild detergent or, in the case of heavy contam-
ination, soak and carefully push through. Rinse in cold water. Avoid high mechanical loads
(water jet).
Let the filter ring dry completely before assembling.
Dirty water and mild detergent must be disposed of in compliance with locally applicable
regulations.
Cleaning the absorption segments
Loosen and remove lock nuts (81273).
Loosen and remove screws (81272) to the connecting rods (81269).
Remove connecting rods (81269).
Remove and clean cover grid (81266).
Pull out insert units (E), bend up sheet-metal coverings (81137), then take out absorption
segments (81136).
Clean the absorption segments (81136).
When cleaning, note that the absorption segments (81136) must only be cleaned lightly
with pressurized air, with a soft brush or a moist cleaning cloth.
Have any heavily contaminated absorption segments and filter rings as well as damaged
connecting rods replaced by an ABB Turbocharging Service Station.
Fitting the filter silencer
Assemble the insert units (E) by inserting the absorption segments (81136) into the sheet-
metal coverings (81137).
Bend the sheet-metal coverings (81137) back into the original shape.
Insert the insert units (E) into the slotted guides in the filter silencer body (81135).
Place the cover grids (81266) evenly and in the correct position.
Push the connecting rods (81269) through the lugs of the cover grids (81266).
Penetration of dirt and foreign particles
Any penetration of dirt and foreign particles into the compressor can damage
it.
Fit the connecting rods (81269) correctly in the slots on the filter silencer
body (81135).
It must not be possible to rotate or move the cover grid (81266) after
assembly.
Check the position and alignment of the connecting rods during and after
assembly.
