Configurable logic blocks Q/T Total number of instances
RSMEMORYQT 40
SRMEMORYQT 40
TIMERSETQT 40
XORQT 40
Table 6: Total number of instances for extended logic package
Extended configurable logic block Total number of instances
AND 180
GATE 49
INV 180
LLD 49
OR 180
PULSETIMER 89
RSMEMORY 40
SLGAPC 74
SRMEMORY 130
TIMERSET 109
VSGAPC 120
XOR 89
IEC 61850 or
function name
ANSI Function description Generator
REG670
(Customized)
Monitoring
CVMMXN Power system measurement 6
CMMXU Current measurement 10
VMMXU Voltage measurement phase-phase 6
CMSQI Current sequence measurement 6
VMSQI Voltage sequence measurement 6
VNMMXU Voltage measurement phase-ground 6
AISVBAS General service value presentation of analog inputs 1
EVENT Event function 20
DRPRDRE,
A4RADR,
Disturbance report 1
SPGAPC Generic communication function for Single Point indication 64
Table continues on next page
1MRK 502 073-UUS A Section 3
Available functions
Generator protection REG670 2.2 ANSI and Injection equipment REX060, REX061, REX062 39
